288 Troubleshooting
 Protrudent/Bumpy Paper
NOTE:
• If the problem continues even though you have taken suggested actions described above, contact the Fuji Xerox local
representative office or an authorized dealer.
Problem Action
Printed surface got
protrudent/bumpy.
Clean up the fusing unit.
1 Load one sheet of paper on the standard 150 sheet tray, and then print a solid
image all over the paper.
2 Load the printed sheet with the printed side facing down, and then print a blank
sheet of paper.

Fuji Xerox DocuPrint CM225FW Specifications

General

Connectivity	USB 2.0, Ethernet, Wi-Fi
Duplex Printing	Automatic
Monthly Duty Cycle	Up to 30, 000 pages
ADF Capacity	15 sheets
Functions	Print, Copy, Scan, Fax
Print Speed	18 ppm (A4)
Print Resolution	1200 x 2400 dpi
Scanner Type	Flatbed, ADF
Paper Size	A4, A5, A6, Legal, Letter
Mobile Printing	AirPrint, Google Cloud Print
Print Technology	Laser (Colour)
