USING SETUP MODE
5-12 User's Manual
*1 FORMAT to CD are not printed when PARALEL option is selected
for INTRFCE.
It is printed equipped with RS-232C.
*2 TEAR-EN is printed when AUTO option is selected for TEAROFF.
Printout of factory defaults using LIST
<< Menu 1 settings >> << Menu 2 settings >>
------------------------- -------------------------
Func. |Item |Option Func. |Item |Option
------------------------- -------------------------
MENU1 |EMULATE|DPL24C+ MENU2 |EMULATE|DPL24C+
MENU1 |FONT |COUR 10 MENU2 |FONT |COUR 10
MENU1 |QUALITY|LETTER MENU2 |QUALITY|LETTER
MENU1 |PITCH |10 CPI MENU2 |PITCH |10 CPI
MENU1 |LINE SP|6 LPI MENU2 |LINE SP|6 LPI
MENU1 |CHAR-W |NORMAL MENU2 |CHAR-W |NORMAL
MENU1 |CHAR-H |NORMAL MENU2 |CHAR-H |NORMAL
MENU1 |ATTRIB |NONE MENU2 |ATTRIB |NONE
MENU1 |PAGE LG|11.0 IN MENU2 |PAGE LG|11.0 IN
MENU1 |LFT-END|1 COLM MENU2 |LFT-END|1 COLM
MENU1 |TOP-MRG|1 LINE MENU2 |TOP-MRG|1 LINE
MENU1 |LANGUGE|PAGE437 MENU2 |LANGUGE|PAGE437
MENU1 |CHR-SET|SET2 MENU2 |CHR-SET|SET2
MENU1 |PRF-SKP|NO-SKIP MENU2 |PRF-SKP|NO-SKIP
MENU1 |WIDTH |13.6 IN MENU2 |WIDTH |13.6 IN
MENU1 |ZEROFNT|NO-SLSH MENU2 |ZEROFNT|NO-SLSH
MENU1 |DC3-CDE|ENABLE MENU2 |DC3-CDE|ENABLE
MENU1 |CR-CODE|CR ONLY MENU2 |CR-CODE|CR ONLY
MENU1 |LF-CODE|LF & CR MENU2 |LF-CODE|LF & CR
MENU1 |RGHTEND|WRAP MENU2 |RGHTEND|WRAP
MENU1 |INT-MEC|DISABLE MENU2 |INT-MEC|DISABLE
MENU1 |==END==| MENU2 |==END==|
------------------------- -------------------------
<< Hardware settings >> << Config settings >>
------------------------- -------------------------
Func. |Item |Option Func. |Item |Option
------------------------- -------------------------
HARDWRE|PPR-OUT|DETECT CONFIG |TEAROFF|MANUAL
HARDWRE|PRT-DIR|BI-DIR CONFIG |TEARPOS|VISIBLE
HARDWRE|BUZZER |ON CONFIG |TEAR-EN|1 SEC (*3)
HARDWRE|WORD-LG|8 BIT CONFIG |CUTLOAD|AUTO
HARDWRE|BUFFER | 8KBYTE CONFIG |LOADTIM|1.5 SEC (*4)
HARDWRE|SENLEVL|100% CONFIG |DECODE |DIRECT
HARDWRE|STANDBY|1MIN CONFIG |FCNTARE|ENABLE1
HARDWRE|INTRFCE|AUTO-2S (*1) CONFIG |RCNTARE|ENABLE1
HARDWRE|FORMAT |8NONE 1 (*2) CONFIG |CUT-ARE|ENABLE1
HARDWRE|BAUD-RT|9600 (*2) CONFIG |CUT-ONL|ONLINE
HARDWRE|PROTOCL|XON/XOF (*2) CONFIG |CNT-ONL|ONLINE
HARDWRE|DSR |IGNORE (*2) CONFIG |LOCK |NONE
HARDWRE|DUPLEX |FULL (*2) CONFIG |//S// |DISABLE
HARDWRE|CTS |DETECT (*2) CONFIG |FCNT-PE|EDGE
HARDWRE|CD |IGNORE (*2) CONFIG |RCNT-PE|EDGE
HARDWRE|==END==| CONFIG |GATHER |DISABLE
------------------------- CONFIG |CUT-CTL|SPEED
<< Adjust settings >> CONFIG |STATUS |DISABLE
------------------------- CONFIG |BANDCTL|DISABLE
Func. |Item |Option CONFIG |TOF-CTL|DRIVER
------------------------- CONFIG |FCNT-SF|DISABLE
ADJUST |FCNTORG|1.8/6IN CONFIG |RCNT-SF|DISABLE
ADJUST |FCNTFIN|0 /180 CONFIG |CUT-SF |DISABLE
ADJUST |RCNTORG|1.8/6IN CONFIG |CUTEDIR|FRONT
ADJUST |RCNTFIN|0 /180 CONFIG |CSFEDIR|REAR
ADJUST |FCUTORG|1.8/6IN CONFIG |CUTEJCT|AUTO
ADJUST |FCUTFIN|0 /180 CONFIG |FL-CENT|POSN1
ADJUST |RCUTORG|1.8/6IN CONFIG |RL-CENT|POSN1
ADJUST |RCUTFIN|0 /180 CONFIG |SKEWCNT|PRCISIN
ADJUST |FCNTBTM|0 /180 CONFIG |FF-CODE|EJECT
ADJUST |RCNTBTM|0 /180 CONFIG |CSFBIN1|FRONT
ADJUST |CUT-BTM|0 /180 CONFIG |CNT-LD |SPEED
ADJUST |CNT-LFT|0 /90 CONFIG |CSF-LD |NORMAL
ADJUST |CUT-LFT|0 /90 CONFIG |CSFAPTC|NORMAL
ADJUST |FCNTADJ|0 /360 CONFIG |LF-CTL |SPEED
ADJUST |RCNTADJ|0 /360 CONFIG |PR-MODE|NORMAL
ADJUST |FCNTAJL|0 /360 CONFIG |HI-IMPT|DISABLE
ADJUST |RCNTAJL|0 /360 CONFIG |LQ-MODE|MODE1
ADJUST |CUT-ADJ|0 /360 CONFIG |DQ-MODE|MODE2
ADJUST |FCSFADJ|0 /360 CONFIG |POW-POS|NORMAL
ADJUST |RCSFADJ|0 /360 CONFIG |AUTO-PR|DISABLE
ADJUST |FCNTLOR|4 /9 CONFIG |==END==|
ADJUST |FCNTLFN|0 /90 -------------------------
ADJUST |RCNTLFN|0 /90 << Gap Adjust settings >>
ADJUST |CUTLOR |1.8/9 -------------------------
ADJUST |CUTLFN |0 /90 Func. |Item |Option
ADJUST |FCNTCUT|99 /180 -------------------------
ADJUST |RCNTCUT|99 /180 GAP-ADJ|AMOUNT |AUTO
ADJUST |CUT-CUT|20 /180 GAP-ADJ|==END==|
ADJUST |FRCSLNT|28/360 -------------------------
-------------------------
To Next Page
