MAINTENANCE
6-10 User's Manual
Position groove 1 over guide pin 1 on the right and left sides of the
stacker unit. Then, push in the stacker unit until guide pin 2 is hooked
onto slot 2.
MOUNTING THE
STACKER UNIT
Guide pin
Guide pin
Groove 1
Slot 2
Groove 1
Slot 2
