INTRODUCTION
1-4 User's Manual
Printer add-on options are listed below. For details, see Chapter 8.
• Cut sheet feeder. The SF940 single-bin feeder is available as an
option. Two cut sheet feeders can be installed in front of and behind
the printer at the same time. A cut sheet feeder allows single cut
sheets and multiple-part cut sheets to be fed automatically.
• Tractor unit. A second tractor unit may be bought as an additional
option if dual tractor feeding capability is required.
• LAN card. A LAN card is available as a printer add-on option. A
user installable function, the LAN card can be installed only on
printer models with the Centronics parallel + USB interfaces. For
details, see Chapter 8.
OPTIONS of DL7600Pro dot matrix printer
SF940 single-bin feeder (front
）
SF940 single-bin feeder (rear
）
Slot for LAN card is available.
(
Centronics parallel + USB interfaces MODEL)
Replacing stacker with large stacker is required
when SF940 is installed in rear side.
