COMMAND SETS
C-14 User's Manual
Bar Code Printing Control
ASCII : ESC + DC4 + b + R + c + w + h + a + ch1 … + chn
Hexadecimal : 1B + 14 + b + 52 + c + w + h + a + ch1 … + chn
Decimal : 27 + 20 + b + 82 + c + w + h + a + ch1 … + chn
(1) Function
(a) Instructs the printing of bar codes according to the different
specifications of this command.
(2) Valid range of parameters
(a) b (Specification of number of bytes) = Actual number of data + 6
(b) R (Fixed)
ASCII : R
Hexadecimal : 82
Decimal : 52
(c) C (Specifies the type of bar code to be printed. No printing is
done if any value other than the following is specified.)
C
Type of bar code
ASCII Decimal Hexadecimal
1 49 31 Codabar (nw-7)
2 50 32 EAN 13
3
51 33 EAN 8
4 52 34 Code 3 of 9
5 53 35 Industrial 2 of 5
6 54 36 Interleaved 2 of 5
7 55 37 Matrix 2 of 5
8 56 38 POSTNET
9 57 39
Intelligent Mail
Barcode
A 65 41 UPC type A
B 66 42 CODE 128
E 69 45 UPC type E
a
97 61
UPC type A with
check character
