COMMAND SETS
User's Manual C-15
(d) w (Specify the width of the narrow bar of the bar code to be
printed in units of 1/1440.)
Specify the “Logical value” to be printed (in units of 1/1440).
Actual printing: The printer prints with the width given in the
following table in units of 1/180 inches.
w W
idth of narrow bar
1 ~ 19 2 Dots (2/180 inches)
20 ~ 27 3 Dots (3/180 inches)
28 ~ 4 Dots (4/180 inches)
This parameter is ignored by POSTNET and Intelligent Mail
Barcode.
(e) h (Specify the height of the bar code to be printed in units of
1/1440 taking the narrow bar width as the reference.)
Height of bar code = (parameter w) × (parameter h) [in units
of 1/1440]
Height of bar code ≤ 11 Inches
Actual printing: The printing is done with the following initial
values if the bar code height is less than or
equal to 24 dots taking 1 dot equal to 1/180
inches of the printing unit of the printer.
The following values are the standard heights for the respective
bar code standards. Enter the value so that the height is ≤
23/180 if the standard is correct.
Narrow bar
width
EAN 13/
UPC-A, E/
Code128
EAN 8 Others
2 Dots
(16/1440)
162 Dots
(1296/1440)
130 Dots
(1040/1040)
108 Dots
(864/1440)
3 Dots
(24/1440)
234 Dots
(1872/1440)
187 Dots
(1496/1040)
135 Dots
(1080/1440)
4 Dots
(32/1440)
312 Dots
(2496/1440)
249 Dots
(1992/1040)
162 Dots
(1296/1440)
Figures in parentheses ( ) are values converted to units of
1/1440.
This parameter is ignored by POSTNET and Intelligent Mail
Barcode.
