INTERFACE INFORMATION
User's Manual D-11
Cable
This printer supports the USB2.0 Full speed specification. To connect to
the host, use USB 2.0-compliant INF cables (5 meters (196 inch) or
shorter). (Use the shielded cables.)
Connector pin alignment
No. Signal line name Function
1 VBUS Power supply
2 D- Data transfer
3 D+ Data transfer
4 GND Signal ground
Shell Shield
- Connector specification
Printer side
Cable side
Type B receptacle (female)
Upstream port
Type B plug (male)
Specification
- Basic specification USB interface compliant
Note
It does not guarantee all operations on hosts.
- Power control Self-power device
- Transmission mode Full speed (Maximum 12 Mbps
+0.25%)
USB INTERFACE
