MAINTENANCE
User's Manual 6-5
3. Remove the ribbon guide.
Removing the ribbon guide
4. To remove the ribbon cassette, pull the underside of ribbon
cassette and carefully lift the cartridge out of the printer.
Removing the ribbon cassette
Triangle mark
Projections
Print Head
Ribbon Guide
