Fujitsu DL7600Pro - Page 212

INSTALLING OPTIONS
8-2 User's Manual
2. Remove metal plate
Remove two screws and metal plate on the parallel port.
Keep metal plate removed.
3. Insert LAN card
Insert the LAN card along both sides of guide rails slowly.
Make sure that LAN card is inserted all the way into the slot.
4. Tighten the LAN card
Tighten the LAN card with two screws removed in step 2.
LAN card
Metal plate
