Chapter 7 Installing Internal Options
7 Install the heat sink.
Attach the heat sink to the installed CPU and fasten it with the screws.
Carefully tighten the screws in diagonal order.
8 Attach the ventilation system cover and top cover.
"7.2 Removing and Attaching the Top Cover" (pg.174)
9 Return the server to the rack.
10 Initialize the Extended System Configuration Data (ESCD).
On the [Advanced] menu of the BIOS Setup Utility, set [Reset Configuration Data] to [Yes].
→[Reset configuration Data] in "8.2.5 Advanced Menu" (pg.230)
11 Store the BIOS settings.
"5.3 Storing the System Setting Information" (pg.142)
■ How to Remove a CPU
To remove a CPU, simply reverse the installation procedures.
