Replacing the Roller Set
450
Replacing the Roller Set
The Roller Set is made up of the brake roller and the pick roller.
The procedure for replacing each roller is as follows.
1. Unplug the power cable from the ScanSnap.
2. Remove the documents from the ADF paper chute (cover).
3. Pull the ADF release tab to open the ADF top section.
4. Replace the brake roller.
1. Open the cover.
Hold both ends of the cover, and open it in the direction of the arrow.
ADF release tab
ADF top section
ADF paper chute
(cover)
To Next Page
