23
3. Attach Air Hose to Laser Cutter: Insert the other end of the black air inlet hose into the “air
inlet” nozzle in the back of laser cutter via the barbed air connect tting.
4. Connect to Power: Plug the air compressor into the upper power plug marked
“air compressor” on the back of your Muse. Note that air compressor will only turn on when the
laser is ring.
Air Compressor
Power Outlet
Air Inlet
Figure 3.14
Figure 3.15
