8. Reattach Universal Laser Pin Connector: Reverse step 8. Screw the universal laser pin
connector onto the aperture end of new laser tube and clip the connector back to the other end of the
laser tube.
9. Place New Laser Tube: Place the new tube into the rubber holders in the same orientation
as the old tube was in when it was removed (with the glass coils oriented to the RIGHT when
facing the machine).
10. Re-Attach Tube Retainer Straps. Gentle place the tube restraining straps back into
position over the rubber holders and secure the new laser tube in place.
11. Re-Thread Hex Nuts. CAREFULLY re-thread the M5 hex nuts onto the U-bolt posts and
make snug (but not yet tight) with the rear panel.
12. Re-Attach Water Tubes. Carefully re-attach the water tubes to the proper laser connection
bulkheads. Make sure that the water tube routing and locations match the original conguration.
We have now switched the old laser tube for the new laser tube.
You will need to retest the mirror alignment and possibly go through the
mirror alignment procedure again.
