3.1 T
erminal unit, IC-215
3-4
Fig.3.1.7 TERM CPU boar
d (16P0209)
PRINTER
DTE
JUNCTION
Not used,
normally ON
CR4
CR5
CR6
CR7
Lithi
um Ba
ttery
JP1:Di
sconnecting
back-up battery
CPU RUN (CR3)
Blinking every
second
DIP switch (S5)
(ALL OFF)
Ethernet
CR8: Rx ON
CR9
: Tx ON
Communication check
[LAN
]
(10BASE-T)
CPU Reset SW
(S1)
UL
TR
A I/O Res
et SW
(S
2)
Q2I Res
et SW
(
S3
)
[KEY BO
ARD]
U7:U
L
T
RA
I/O
U12:Q2I
(LCD CONT)
U14: F-ROM
(Program)
U3: S-RAM
U4: S-RAM
U28: CPU
U30: Ethernet
CONT
U13: RAM
U22: DRAM
U23: DRAM
55
