Furuno FELCOM 15 Service Manual

4.2 Setting from Command Window
4-8
4.2 Setting from Command Window
Followings are set by “Command Window” in [F8]-2: System menu;
- The ON/OFF setting of DMC-5, IC-305 and IC-306 unit
- The NMEA data transmitting cycle
When the alarm unit is installed, the jumper setting for this unit is also needed.
See page 4-11.
4.2.1 Remote Box Setup
When IC-305, IC-306 or DMC-5 are connected, Command Window ([F8]-2, system
menu) controls the installation setting.
1. Select “Command window” ([F8]-2) and then press [Enter].
2. Open the service mode.
JOB NO.: Type “FURUNOSERVICE” and [Enter]
Password: Type “FELCOM15” and [Enter]
In Service mode, the [Main Menu] display is reversed.
3. Press [1] and then [Enter] to select “1. Remote Box Setup”. Start setting according
to the installation.
Reversed.
