Furuno FELCOM 15 Service Manual

3.3 IC-305 and IC-306
3-11
Setting of JP1 and JP2 and installing S1, 2 and 3
16P0213 board has type A and type B. It differs from the jumper setting of JP1 and 2
and the presence of S1, S2 and S3.
Table 3.3.1 16P0213A and B
A type B type
DISTRESS RCV-1 RCV-2 RCV-3
JP1 Short Open Open Short
JP2 Short Short Open Open
S1 YES NO NO NO
S2 YES NO NO NO
S3 NO YES YES YES
