＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
AIL3
(ChipAileron)
AIL4
(ChipAileron)
AIL1
(MainAileron)
AIL2
(MainAileron)
FLP2
(CamberFlap)
FLP1
(CamberFlap)
AIL → Camberflap
[Corresponding model type]: Airplane/
glider, 2 ailerons + 2 Áaps or more
This mix operates the camber flaps (FLP1/2)
in the aileron mode. When the aileron stick
is manipulated, the ailerons and camber flaps
perform aileron operation simultaneously and
the operation characteristic of the roll axis is
improved.
ŏ The aileron left/right mixing rate of each Áap servo
can be Àne-tuned.
ŏ A mixing curve can be set.
ŏ An ON/OFF switch can be set.
ŏ Linking is possible: Link this mix to other mixes.
Adjustmentofeach
flapservo
Setting method
ŏ Tap [INH].
(ON is displayed.)
ŏ When setting a switch, tap the [--] item of
the switch and tap the screen to call the
selection screen, and then select the switch
and set its ON direction. (Always ON at "--"
setting)
(For a description of the switch selection
method, see the description at the back of
this manual.)
ŏ Tap the left or right item of each Áap servo.
Adjust the mixing rate.
*When the mixing direction is reversed by the linkage,
adjustments can be made by changing the mixing rate
SRODULW\RU
ŏ A mixing curve can be set. (1/2 page)
(For a description of the mixing curve setting
method, see the description at the back of
this manual.)
ŏ To set linking, tap the [Link] item.
Set it to ON and tap the screen.
ŏ Select [AILńCamber flap] at the
model menu and call the setup
screen shown below.
Currentlyselectedconditionname
● Mixingcurvesetting
(Foradescriptionofthe
settingmethod,seethe
descriptionattheback
ofthismanual.)
Left/rightoverall
adjustmentatRateA
andRateB
Activatethefunctionby
tappingthe[INH].
Conditiongroup/single
modeselection(Gr./Sngl)
TheON/OFFswitchof
mixingischosen.
Tosetlinking,tapto
the[OFF]item
ŏReturn to Model menu
