＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
AIL3
(ChipAileron)
AIL4
(ChipAileron)
AIL1
(MainAileron)
AIL2
(MainAileron)
FLP3
(BrakeFlap)
FLP4
(BrakeFlap)
AIL →Brakeflap
[Corresponding model type]: Airplane/
glider, 4 Áaps or more
This mix operates the brake flaps (FLP3/4)
in the aileron mode. When the aileron stick
is manipulated, the aileron and brake flaps
perform the aileron operation simultaneously
and the operation characteristic of the roll axis is
improved.
ŏ The aileron left and right mixing rates can be
adjusted for each Áap servo.
ŏ A mixing curve can be set.
ŏ Mixing during Áight can be turned ON/OFF by
setting a switch. (Always ON at [--] setting)
ŏ Linking can be set: Link this mix to other mixes.
Ɣ6HWWLQJPHWKRG
ŏ Tap to the INH item.
(ON is displayed.)
ŏ When setting a switch, tap to the [--] item
of the switch and tap the screen to call the
selection screen, and then select the switch
and set its ON direction. (Always ON at "--"
setting)
(For a description of the switch selection
method, see the description at the back of
this manual.)
ŏ Tap the left or right button of each Áap servo.
Adjust the mixing rate.
*When the mixing direction is reversed by the linkage,
adjustments can be made by reversing the mixing rate
SRODULW\RU
ŏ A mixing curve can be set.
(For a description of the curve setting
method, see the description at the back of
this manual.)
ŏ To set linking, tap to the Link item.
Set it to ON and tap the screen.
ŏ Select [AILń Brake flap] at the model
menu and call the setup screen shown
below.
Adjustmentofeach
flapservo
Currentlyselectedconditionname
● Mixingcurvesetting
(Foradescriptionofthe
settingmethod,seethe
descriptionattheback
ofthismanual.)
Left/rightoverall
adjustmentatRateA
andRateB
Activatethefunctionby
tappingthe[INH].
Conditiongroup/single
modeselection(Gr./Sngl)
TheON/OFFswitchof
mixingischosen.
Tosetlinking,tapto
the[OFF]item
ŏReturn to Model menu
