＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
Gyro
[Corresponding model type]: Airplane/glider/multicopter, general
This function is used when a GYA Series gyro
is used to stabilize the aircraft's attitude. The
sensitivity and operation mode (Normal mode/GY
mode) can be switched with a switch.
ŏ Three rates (Rate 1/Rate 2/Rate 3) can be
switched.
ŏ Up to 3 axes (Gyro/Gyro 2/Gyro 3) can be
simultaneously controlled.
*Initial setting does not assign a sensitivity channel. Use the
Function menu of the Linkage menu to assign the sensitivity
channel (Gyro/Gyro2/Gyro3) used to a vacant channel
beforehand.
6HW>&RQWURO@DQG>7ULP@RWKHUWKDQ)XQFWLRQWR>@
ŏ Three rates (Rate 1/Rate 2/Rate 3) can be used.
Tap to the [Rate] item. Adjust the rate.
ŏ When using this function, Tap [INH].
ŏ When a Futaba GYA gyro is used, when [GY] type is selected, the
sensitivity set value is directly read in both the AVCS and Normal modes.
ŏ When setting a switch, tap the Switch item and tap the "--" button to call
the selection screen, and then select the switch and set its ON direction.
(For a description of the switch selection method, see the description at
the end of this manual.)
ŏ Select [Gyro] at the model menu and
call the setup screen shown below.
Theoperationmode
(AVCS/NOR)and
sensitivityofthe3
axesGyro/Gyro2/
Gyro3canbeset.
3rate(gyrogain)
adjustment
Conditiongroup/
singlemodeselection
(Gr./Sngl)
TheON/OFFswitchof
gyroischosen.
TappingthiswillchangeINHtoeitherONorOFF
andenableoperation.Adjustmentofthethree
rates(sensitivity)andswitchingbetweenNormal
andAVCSispossible.
ŏReturn to Model menu
