＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
([DPSOH6HWWLQJWKUHHD[LVXVLQJD*<$DQG*<$
ŏ Wing type: Aileron 2 servos mounted fuselage selected
ŏ Set
5CH → Gyro
(GYA431AIL),
7CH → Gyro2
(GYA431ELE),
8CH → Gyro3
(GYA430RUD),
ControlandTrim → "--"
: at
the Function menu of the Linkage menu.
ŏ Gyro setting of the Model menu.
*Set so that Rate 1 is turned on at the back position of switch E
and Rate 3 is turned ON at the front position. Since switch E is
turned OFF at the center, Rate 2 remains [INH].
Rudderservo
Elevatorservo
GYA430
GYA431
GYA431
Aileronservo
S.BUS2port
R7008SB
GAIN0％
AVCS
NORMAL
WhenAVCSisusedwe
recommendthatthe
sensitivityCHbesetto
the3-position.
Rate ACT Type Switch Gyro Gyro ２ Gyro ３
1 OFF/ON GY SE AVCS:60% AVCS:60% AVCS:60%
2INH
3 ON/OFF GY SE Normal:60% Normal:60% Normal:60%
