＜ Modelmenu(Airplane/Glider/MulticopterFunctions) ＞
ELEVATOR
ELEVATOR2
(AILERON5)
(AILERON6)
Ailevator
[Corresponding model type]: Airplane/glider, Tail type
Ailevator
(Effective only when 2 servos used at the elevators)
This function improves the operating
performance of the roll axis by operating the
elevators as ailerons.
Ailevator is where each elevator in a standard
FRQYHQWLRQDORUYWDLOPRYHVLQGHSHQGHQWO\OLNH
ailerons on a wing. In addition to each elevator side
moving up and down together, each side moves in
opposite directions when moving as an ailevator.
2QD9WDLOWKLVLVDOVRNQRZQDVDUXGGHUYDWRU
as they can serve the same purpose. Typically,
both ailevator and ailerons are coupled together to
maximize roll performance, especially on larger
wingspan planes.
Note: Select ailevator as the Model type at the
Model type screen. This changes the output
channel. Check the Function menu.
ŏ Select [Ailevator] at the model
menu and call the setup screen
shown below.
ŏ Travel adjustment
Tap to the item you want to adjust.
Adjust the rate by "ʈʈ" "ʈ" "ʆ" "ʆʆ"
button.
*If the mixing direction is reversed by the linkage,
adjustments can be made by changing the mixing rate
SRODULW\RU
,IDODUJHYDOXHRIWUDYHOLVVSHFL¿HGZKHQWKHVWLFNVDUH
moved at the same time, the controls may bind or run out
of travel. Decrease the travel until no binding occurs.
(Aileronfunction)
Whentheelevatorsareusedas
ailerons,ailerontraveloftheleftand
rightelevatorscanbeadjusted.
(Elevatorfunction)
Theupanddownratesoftheleftand
rightelevatorswhentheelevatorstickis
manipulatedcanbeindividuallyadjusted.
Conditiongroup/
singlemode
selection(Gr./Sngl)
ŏReturn to Model menu
