＜ Data ＞
ŲƓƈƕƄƗƌƒƑƖŃƕƈƏƄƗƈƇŃƗƒŃƲƑƈŃƗƘƑƌƑƊŃŹŵ
[Fine tuning VR operation mode]
[LIN.] Mi x in g r at e 0 at center of VR.
When the VR is turned clockwise and
counterclockwise, the mixing rate
increases and decreases, respectively.
[ATL+] Mixing rate 0 at left end of VR.
When the VR is turned, the mixing rate
increases.
[ATL-] Mixing rate 0 at right end of VR.
When the VR is turned, the mixing rate
increases.
[SYM.] When the VR is turned to the left or
right of the neutral position, the mixing
rate increases.
[Setting method]
1. Control selection
Tap the [Control] "--" button to call the
<Hardware select> screen, and then select
the switch and its ON direction.
2. Mode selection
Tap the [Mode] button, and then select the
mode ([LIN.], [ATL+], [ATL-], or [SYM.]).
3. Rate adjustment
Tap the [Rate] "value" button.
Set the rate by
"▼▼""▼""▲""▲▲"
button.
Initial value: 0
Adjustment range: -100~+100
(When the value is tapped, the rate is reset to the initial
value.)
VRselection Rateadjustment
(FinetuningVRoperationposition)
Operationmodeselection
*Theoperationmodeswhichcanbe
selecteddependonthefunction.
LIN. SYM.ATL+ ATL-
Aftersetting,pressaHOME/EXITbutton
