176
＜ Data ＞
Logic mode
AND: When both switches are ON, the
condition is ON.
OR: When either switche is ON, the
condition is ON.
EX-OR: When the two switches are in
different states, the condition is ON.
Switch mode selection
1. Tap to the [Mode] "Single" item.
(Logic switch setting screen)
Switch selection
1. Select the switch A and B.
Logic mode selection
1. Tap to the [Logic] item.
2. Select the logic mode.
Logic switch (Condition select function only)
The logic switch function lets you turn operation on and off by combining two switches. For instance,
the condition is activated when 2 switches are turned on.
