FUTABA T18SZ - Page 34

34
＜ BeforeUse ＞
ŵŚœœśŶť

ŦūŃŰƒƇƈ
The R7008SB receiver is a very versatile
unit. It has 8 PWM outputs, S.BUS and S.BUS2
outputs. Additionally the PWM outputs can be
changed from channels 1-8 to channels 9-16. If
you only desire to use it as an 8 channel receiver
(without S.BUS), it can be used without any
setting changes.
The T18SZ has the ability to link to two
R7008SB receivers. One of them outputting
channels 1-8 and the other outputting channels
9-16 gives you 16 PWM channels. Instructions
for this configuration and S.BUS operation
follow.
[How to change the R7008SB Channel mode.]
1. Press and hold down the Link/Mode button
on the 56% receiver.
2. Turn the receiver on while holding down
the Link/Mode button. When the LED
begins to blink green/red the button may
be released.
3. The LED should now be blinking red in one
of the patterns described by the chart
below.
4. Each press of the Mode/Link button
advances the receiver to the next mode.
5. When you reach the mode that you wish
to operate in, press and hold the Mode/
Link button for more than 2 seconds.
6. Once locked into the correct mode the
LED will change to a solid color.
7. Please cycle the receiver(s) power off and
back on again after changing the Channel
Mode.
Receiver
connector
Settingchannel
ModeA
1 〜 8CH
ModeB
1 〜 7CH
ModeC
9 〜 16CH
ModeD
9 〜 15CH
1 1199
2221010
3331111
4441212
5551313
6661414
7/B 7 7 15 15
8/SB 8 S.BUS 16 S.BUS
RedLEDblink 1time 2times 3times 4times
R7008SB CH MODE TABLE
DANGER
Don'ttouchwiring.
*Thereisadangerofreceivinganelectricshock.
Donotshort-circuitthebattery
terminals.
*Ashortcircuitacrossthebatteryterminalsmay
causeabnormalheating,fireandburns.
Pleasedoublecheckyourpolarity
( ＋ and − )whenhookingupyour
connectors.
*If＋and −ofwiringaremistaken,itwilldamage,
igniteandexplode.
Don'tconnecttoExtraVoltagebefore
turningonareceiverpowersupply.
