＜ BeforeUse ＞
Whenthemodelisnotbeingused,alwaysremove
ordisconnectthebattery.
■ When the switch is off, a slight amount of
current still flows. Unless the switch and battery
are disconnected, the battery will be damaged
from excessive discharge.
Alwaysmakesurethattheswitchharnessisfirmly
attachedtothefuselageofthemodel.
■ There is the danger of loss of control and
crashing if the connector is disconnected by
vibration and shock.
Donotchargethereceiverbatterythroughthe
switchharness.Disconnectthereceiverbattery
andchargetothemanufacturer'sinstructions.
■ There is no charge connector in this switch.
Neverreversethebatterypolarity.
■ Reverse connection will immediately destroy
the receiver, servo, etc.
Ensurethattheunitismountedinanareathatwill
eliminateexposuretofuel,waterandvibration.
■ As with any electronic components, proper
precautions are urged to prolong the life and
increase the performance of the ESW-1J.
Allowaslightamountofslackinthecablesand
fastenthematasuitablelocationtopreventany
damagefromvibrationduringflight.
NeversoldertheESW-1Jorattempttorepair,
deform,modifyordisassemblethem.
DonotusetheESW-1Jwithanythingotherthanan
R/Cmodel.
Futaba Corp. will not be responsible for damage
caused by combination with other than genuine
Futaba parts.
WARNING
Receiver
Thereceiverpowersupply
canbeconnectedtoany
port.
WhentheswitchisOFFthere
isasmallamountofcurrent
flowingthroughit.Thiswill
damagethebatteryandor
switchsopleasedisconnect
thebatterywhennotbeing
usedforlongperiodsoftime.
Donotchargethe
receiverbatteries
throughtheelectronic
switch.Disconnect
thebatteryfromthe
switchandchargetothe
manufacturer'sdirections.
Switch
＜ Attachment ＞
Lessthan5mmof
mountingplate
Attachedscrew
Switchcover
Use the mounting plate from the receiver on/
off switch as a template for the cutout and screw
holes. Mount the switch on the side of the fuselage
RSSRVLWHWKHHQJLQHH[KDXVWDQGZKHUHLWZRQ¶W
be inadvertently turned on or off during handling
or storage. Be certain the switch moves without
restriction and “snaps” from ON to OFF, and that
the cutout allows full motion of the switch in both
directions.
ŶƚƌƗƆƋŃƋƄƕƑƈƖƖ
This switch ESW-1J connects a Futaba receiver to a battery and is turned on and off in an FET circuit.
Compared to using a mechanical switch, it allows more current to be sent with less loss.
Battery
ųƕƈƆƄƘƗƌƒƑƖŃ
