Gantner GAT Access 6100 Series User Manual

GAT Access 6100 Terminal Series
Commissioning & Configuration
www.gantner.com HB_GAT-ACCESS6100--EN_14 55
Function
No function - Relay is not used
Entrance - Relay will be activated as configured in 'Pulse
time'
ExternalLocking - Relay will be activated when a data
carrier was read by the reader, deactivated when the
process ends
Selection
No_Function /
Entrance /
External Locking
Optocoupler 1
Status input for feedback
Function
No function - Optocoupler is not used
Entrance - Feedback of an Entrance
External Locking - Input for the locking of the terminal
External Release - Input for an external release button
Selection
No function /
Entrance /
External Locking /
External Release
Event trigger
An event is triggered if the Optocoupler input signal
matches the configured setting
Selection
Rising edge /
Falling edge /
Rising & falling e./
State high /
State low
Feedback Lock
If the signal on the optocoupler is active, the terminal is
locked until the signal drops again
Boolean
true
Fingerprint
Verification Level
Verification level of the finger print sensor. Can be set
between 0 and 10, the recommended value is 5. A
higher value decreases the false acceptances rate; a
lower value decreases the false rejections.
Integer
5
Mode Verification
Defines, how the finger print sensor is used:
Deactivated - Finger prints are not used
Data on Card - The finger prints of the users are stored
on their data carriers for verification.
Compatibility - If the host responds to the Card_Ident
Command with the state 0x00, the Verification process
is started (Compatibility Mode)
Selection
Deactivated /
Data on Card /
Data on Data-
base /
Compatibility
Number Fingers
Number of different fingers usable for verification
Integer
2
Site key
Site key to read/write fingerprint data from data carriers
Hex
Thin Finger Mode
Mode to support special thin/small fingers of users.
Boolean
false
Display
Contrast
Contrast of the display. Can also be set in the service
menu of the device.
Integer
0 .. 63
Brightness active mode
Brightness of the screen backlight, when the device is in
standard operation mode.
Integer
0 .. 80
Brightness energy save
Brightness of the screen backlight, when the device is in
energy save mode.
Integer
0 .. 80
Energy save Delay
Idle time in milli seconds before device switches to the
energy save mode
Integer
360000
Application
General
Sound signals enabled
With this option you can enable sound signals at the
device, for better user feedback. When this option is
deactivated, no sound signals are output
Boolean
Time format
Time format used to show time values at the device
Selection
0 - 24 / AM / PM
Use alternative Font
When this option is marked, an alternative font can be
used for text display at the the screen (see next option).
If not marked, the standard font is used.
Boolean
Font loaded
The alternative font, that is loaded and can be used with
the previous option
Text
Cyrillic
Emergency Mode enabled
Enable the Emergency Mode
Boolean
True
