GAT Access 6100 Terminal Series
Troubleshooting & FAQ
www.gantner.com
HB_GAT-ACCESS6100--EN_14
89
8.14 The relay of the GAT Access 6100 is activated even if the host has denied access.
The relay is configured as "External_Locking" and is activated, as soon as the access terminal has read the unique
number UID of a data carrier.
Solution:
Set the relay to "No_Function" or "Turnstile" function.
8.15 Which FUNLINE protocol commands are supported by a GAT Access 6100?
Offline Commands:
- Set_Address - Repeat_Event - Set_Addr_Extended
- Set_Date - Delete_Events - Set_Protocol_Type
- Ident_Read_Date - Pass_Master - Enable_Baptism
- Test_Connection - TriggerMasterMode - Read_Baptism
- Read_Event - Reset - Clear_Baptism
Online Commands:
- Pass_Master - Card_Ident - Action_Started
8.16 Why does the GAT Access 6100 deny access with my data carrier in Emergency mode?
In emergency mode a GAT Access 6100 reads a certain segment (LEGIC: configurable, MIFARE: locker segment,
ISO 15693: general segment) of the data carriers. If the site-key is correct (same site-key on data carrier and in the
terminal) access is granted, otherwise the data carrier is rejected and access is denied.
8.17 What is the maximum start-up current consumption of a GAT Access 6100?
V
In
I
max
12 V 7 A
16 V 10 A
20 V 12 A
24 V 15 A
8.18 What are the default settings of a GAT Access 6100?
Ethernet:
- TCP Communication Port: 8000
- DHCP enabled: true
- Static IP Address: 192.168.1.37
- Static Subnet Mask: 255.255.255.0
- Static Primary DNS Server: 192.168.1.13
- Static Secondary DNS Server: 192.168.1.11
- Static Default Gateway: 192.168.1.6
- NetBIOS name: GA<PartNo.><SerialNo.>
- 100 Mbit Ethernet enabled: true
