GCC Technologies AFR-24S - Page 76

AFR-24S User Manual
76
Step 7 Lower down the lever to raise the pinch roller.
Step 8 Press “ENTER” key to start media width sizing.
Step 9 Go to “MISC” menu, use arrow left/right keys to select “Adjust Paper” and press
“ENTER” key. Set the “Adjust Paper” to 22.5mm and press “ENTER” key to confirm.
Offline For System Setup
[MISC]
Adjust Paper 22.5 mm
Select: OK: ENTER
