Chapter 2: Front panel programming
104 Vigilant VS1 and VS2 Technical Reference Manual
To display panel configuration options:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3. Choose Panel Configuration.
4. Program the options.
Main Menu
Reports
Test
Control
Program
⇩
Program
Incremental Program
Auto Program
Advanced Program
⇩
Advanced Program
Loop Configuration
Panel Configuration
Panel Operation
NAC programming
The NAC circuits connected to the system must be programmed with the type of NAC,
label, correlation groups, and event notification. Each NAC must be programmed
separately.
Table 27: NAC programming options
Option Description
Class Select either Class A or Class B.
Note: NAC 3 and 4 cannot be set to Class A. If NAC 1 and 2 are set
to Class A, NAC 3 and 4 automatically configure to accept the Class
A return.
Type Set NAC type to:
Continuous (silenceable or nonsilenceable): For strobes and
notification appliances that self-generate a temporal pattern
Temporal (silenceable or nonsilenceable): Universal 3-3-3 pattern
required for evacuation signals by NFPA 72. Used when notification
appliances are not capable of self-generating a temporal pattern.
Genesis (nonsilenceable or with audible silence or with
audible/visible silence): For Genesis and Enhanced Integrity horns
and strobes. Genesis and Enhanced Integrity appliances maintain
synchronization per UL 1971.
Nonsilenceable: Horns cannot be silenced and strobes flash
Audible silence: Horns can be silenced while strobes continue
to flash
Audible/visible silence: For Genesis devices only, connected
horns can be silenced and strobes turn off
Coder (basic, continuous, 120 SPM, or temporal): Used to provide
four-digit coded output in response to alarm conditions. When the
