Chapter 2: Front panel programming
78 Vigilant VS1 and VS2 Technical Reference Manual
Programming events
Advanced programming lets you create custom responses to these types of events:
• Panel events
• Loop events
Advanced programming for panel and loop events is covered in the last two topics in
this chapter.
Changing loop configuration options
Loop configuration options
Loop configuration includes the following programmable options:
Table 22: Loop configuration options
Option Description
Loop class Indicates whether the loop is wired Class A or Class B.
Zone Select this option to add a zone.
Correlation Groups Select this option to add correlation groups.
Device Select this option to add devices.
Mapping Select Yes to enable mapping. Select No to disable mapping.
Loop 2 Enable [1] Select Yes to enable Loop 2. Select No to disable Loop 2. [1]
Loop 2 Fst Grp [1] [2] Select:
001 to 025 to combine loop 1 and 2 devices in the same fast groups, or
101 to 125 to use separate fast groups for Loop 2 devices.
[1] Displayed in dual loop systems only.
[2] See “Programming fast groups for sounder bases” on page 85.
Most options have a factory default setting that you can accept or change.
See “Factory default settings” on page 35.
