Chapter 2: Front panel programming
Vigilant VS1 and VS2 Technical Reference Manual 83
To remove all members from a correlation group:
1. Press the Menu button and choose Programming.
2. Choose Advanced Program and enter the level 2
password.
3 Choose Loop Configuration.
4. Choose Correlation Groups.
5. Enter the number of the correlation group. (Values
range from 001 to 199.)
6. Choose Remove All. A warning message is displayed.
7. Choose Continue to remove all members from the
group.
— or —
Press the Cancel button to return to the previous
level without removing all members.
Note: Removing all members from a correlation group
resets the activation count to 1 and disables in-suite
signal silence.
Advanced Program
Loop Configuration
⇩
Loop Configuration
Loop Class
Zone
Correlation Groups
⇩
Correlation Groups
Number 003<>
⇩
Correlation Group 001
Add/Remove Device
Suite Sig Sil No
Activation Count
Copy
Remove All
⇩
ALL GROUP MEMBERS
WILL BE LOST!
Continue
Cancel
Programming in-suite signal silence
In-suite signal silence is programmed using two separate menus:
• Configure the elapse timer for in-suite signal silence by displaying the Program >
Advanced Program > Panel Operation menu.
• The functionality is enabled for individual correlation groups through the
Program > Advanced Program > Loop Configuration > Correlation Groups menu.
This section provides instructions for setting both in-suite signal silence options.
Note: When Setting up correlation groups for in-suite signal silence, the group’s
activation count must be set to 1. See “Setting a correlation group’s activation count”
on page 81.
