GE DR60 - Dry-contact Relay Outputs

DR60
DR60-TM-EN-2A
109
Bitrate
1200, 2400, 4800, 9600, 19200, 38400 bps
Databits
7 or 8
Stopbits
1 or 2
Parity
None, even, odd
Connector
DB9 (female), standard DTE
Isolation Level
1.44 KVdc
1.5 Dry-contact Relay Outputs
IN SERVICE contact
Description
Dry contact relay, normally closed
Switching Voltage
250 V ( AC and DC)
Permissible current continuous
5 A
Maximum voltage
300 (AC and DC)
Making Capacity
15 A, 4 sec
Breaking Capacity
40W Resistive, 25 W/VA L/R = 50
Dropout time
< 5 ms
Burden
~50mA @12V [600mW]
Withstand voltages across open
contacts
1000V rms
Permissible short time value for 1s
30A
