GE DR60 - Alarm and Warning Reporting

DR60
58
DR60-TM-EN-2A
Item
Description
Recorder status
Shows if the respective recorder is enabled or disabled
Recording made
Shows that a trigger was generated*
Fault number
Shows how many triggers were generated**
Memory used
Shows the percentage usage of the respective recorder
Pre-trigger time
Shows the pre-trigger time configured
Post-trigger time
Shows the post-trigger time configured
Maximum record
time
Shows the maximum recorder time configured
Retrigger enabled
Shows if the retrigger is enabled or disabled
Sample rate
Shows the configured sampling rate for the respective
recorder
Inhibition time
Shows the duration that the trigger generation will be
disabled***
Inhibition count
Shows how many consecutive triggers within the inhibition
time window are needed to enable the trigger inhibition***
Inhibition window
Shows the time that is needed to enable the trigger
inhibition***
*This information is 1 when record is generated and 0 during the record generation.
**The counter restarts when the equipment reboots or a new configuration is sent.
***Parameter configured in configuration tab Recording> Disable for.
7 Alarm and Warning Reporting
The DR60 can report alarm/warning using the dry contact normally closed relay or via
communication protocols (MMS and GOOSE).
The alarm events, in addition to the protocol transmission, will also operate the IN
SERVICE normally closed dry contact relay.
Warning events can only be sent via protocol.
The table also presents the IEC 61850 data name/address to be used when creating a
dataset for these alarms/warnings.
Alarms
Data Name
Description
Sync NOT OK
BSE/ALARMSGGIO1.ST.Alm1
