GE DR60 - Page 59

DR60
59
DR60-TM-EN-2A
Card not detected, invalid
or incompatible
BSE/ALARMSGGIO1.ST.Alm2
Happens when there are
discrepancies between the
installed boards and the
device CORTEC
Internal voltage
BSE/ALARMSGGIO1.ST.Alm3
Internal voltage
automonitoring alarm
Internal temperature
BSE/ALARMSGGIO1.ST.Alm4
Internal temperature is
abnormal (Out of -10°C to
60ºC)
No communication
Ethernet interface 1
BSE/ALARMSGGIO1.ST.Alm5
Loss of communication
with ethernet interface 1
Waveform/Fault recorder
memory usage above 98%
BSE/ALARMSGGIO1.ST.Alm6
Happens when the
memory becomes 98% full
for waveform recorder
Disturbance recorder
memory usage above 98%
BSE/ALARMSGGIO1.ST.Alm7
Happens when the
memory becomes 98% full
for disturbance recorder
Trend recorder memory
usage above 98%
BSE/ALARMSGGIO1.ST.Alm8
Records memory exceeds
98% for trend recorder
SOE recorder memory
usage above 98%
BSE/ALARMSGGIO1.ST.Alm9
Records memory exceeds
98% for SOE recorder
GOOSE subscriber failure
or timeout
BSE/ALARMSGGIO1.ST.Alm10
Time for the next expected
GOOSE message to come
exceeded
Warnings
Data Name
Description
Sync OK
BSE/ALARMSGGIO1.ST.Wrn1
Equipment not sync
No communication
Ethernet interface 2
BSE/ALARMSGGIO1.ST.Wrn5
Loss of communication
with ethernet interface 2
Waveform/Fault recorder
memory usage above 90%
BSE/ALARMSGGIO1.ST.Wrn6
Happens when the
memory becomes 90% full
for waveform recorder
