3.4 Opening a Pre-existing Configuration File
In order to open a pre-existing configuration, click on the <Open> button on the initial
screen of the DR60 Configurator.
It opens the Windows© folder where the configuration files are saved:
Choose the configuration file and the Main Screen of the DR60 Configurator will open,
with the selected configuration file loaded.
It is also possible to open a configuration file from the Main Screen of the DR60
Configurator, by selecting the option Open Configuration on the menu on the Menu
Bar.
3.5 Saving a Configuration File
To save an opened configuration, select the option Save Configuration or Save
Configuration As, on the File menu of the Main Screen of the DR60 Configurator.
When saving a configuration, the DR60 Configurator will create three different files:
*.CID file: saves the communication and recorders configuration. The DR60 uses the SCL
schema 3.1 from the IEC 61850 data models;
*.st file: saves the logic equation and the matrix of I/O and triggering configuration
according to the IEC 61131 Structured Text Language (STL).
*extref: saves the external references for the GOOSE subscriber configuration.
3.6 Sending a Configuration File for the Equipment
To send a configuration file to online equipment, select the option Send Configuration,
on the Menu Bar.
4 Tools
The Tools section of the Initial screen presents two different tools:
Log: monitored and downloads the DR60 logs
Administrative Tools: Firmware upgrade, password management, equipment license
upgrade and support file download.
