1.11 Binary Outputs
Digital outputs specifications
Description
Dry contact relay, normally open
Switching Voltage
250 V ( AC and DC)
Maximum continuous current
5 A
Maximum voltage
300 (AC and DC)
Making Capacity
15 A, 4 sec
Breaking Capacity
40 W Resistive, 25 W/VA L/R = 50
Operation time
< 5 ms
Dropout time
< 15 ms
Burden
Per energized output relay: ~50mA
@12V [600mW]
Withstand voltages across open
contacts
1000V rms
Permissible short time value for 1s
30A
1.12 Environmental Conditions
Environmental Conditions
Operating temperature range
- 40 … +55 °C (–40°F to +131°F)
Maximum operating altitude
2000 m (6560 ft)
Relative humidity
5 … 95 %, noncondensing
As tested per 60068-2-1
-40°C
