5 Configuration Tabs
5.1 General
The General configuration tab contains information related to the physical device logical
node (LPHD) of the DR60.
On this screen, it is shown the information of the respective device:
▪ Model (CORTEC)
▪ Vendor (General Electric Company)
▪ Hardware Version
▪ Firmware Version
▪ Serial Number
Moreover, the following parameter can be configured:
▪ Identifier: Up to 61 characters. Possible characters: a-z, A-Z, a-9, _.
▪ Location: Up to 255 characters. Possible characters: a-z, A-Z, a-9, _.
▪ Owner: Up to 255 characters. Possible characters: a-z, A-Z, a-9, _.
▪ LPHD Prefix: Up to 11 characters. Possible characters: a-z, A-Z, a-9, _.
▪ Electric Power System: Up to 255 characters. Possible characters: a-z, A-Z, a-9,
_.
▪ Primary Operator: Up to 255 characters. Possible characters: a-z, A-Z, a-9, _.
▪ Secondary Operator: Up to 255 characters. Possible characters: a-z, A-Z, a-9, _.
▪ Master Resource Identification: Up to 255 characters. Possible characters: a-z,
A-Z, a-9, _.
▪ Latitude: Possible characters: 0.0-90.0.
▪ Longitude: Possible characters: 0.0-180.0.
▪ Altitude: Possible characters: 0.0-10000.0
5.2 Analog
The Analog configuration tab contains configurations related to the analog channels and
circuits and it is divided into two sub-tabs: Instrument Transformer (TCTR/TVTR); and
Bay Arrangement (MMXU/MMXN).
5.2.1 Bay Arrangement (MMXU/MMXN)
This window allows the configuration of the analog inputs. The configuration includes
the circuit description tag, association with physical inputs, nominal values for
