▪ Max Events: Maximum number of events that can be buffered for
each class. Range 1 to 200.
▪ Mask: Enables the transmission of the respective DNP3 class.
Object Variation
Defines the variation of the respective object to be reported when the master
does not request any specific type.
▪ Object 1 – Binary Inputs - Options: 1 – With status; 2 – Without status
▪ Object 2 – Binary Input Event - Options: 1 – Without timestamp; 2 – With
timestamp; 3 – With relative timestamp
▪ Object 30 – Analog Input - Options: 1 – (32) Integer; 2 – (16) Integer; 3 - (32)
Integer without flag; 4 - (16) Integer without flag
▪ Object 32 – Analog Input Event - Options: 1 – (32) Integer without timestamp;
2 – (16) Integer without timestamp; 3 - (32) Integer with timestamp; 4 - (16)
Integer with timestamp
Input Selection
▪ Binary
▪ Analog
▪ Scale: Scale factor that multiplies the analog measurement
▪ Deadband: An event is triggered when the Analog input changes an
amount greater than the deadband value. A Deadband of zero
permits any change in the analog input value to generate an event,
and a Deadband of full range of the variable prevents generation of
an event
Note: Only float measurement marked with the suffix .f|MX are able to be transmitted via
DNP3.
5.5 Synchronization
5.5.1 Synchronization
The DR60 supports time synchronization with PTP IEEE1588v2 and demodulated IRIGB-
004. It is also possible to configure the DR60 to work with no time sync, just with the
internal clock.
The following parameters are found on this configuration sab:
Time source:
