GE DR60 - DC Transducer Inputs; Binary Inputs

DR60
DR60-TM-EN-2A
112
Input Isolation
>3,5 kV
>3,5 kV
>3,5 kV
¹ - Gauging performed using waveform measurement
1.9 DC Transducer Inputs
DC Transducer inputs specifications
Characteristic
Voltage transducer input
Current transducer input
Measurement
range
- 12,5 to + 12,5 V
0 to 25 mA
Accuracy
± 0.1 % of FS magnitude
range
± 0,1 % of FS magnitude
range
Impedance
> 5 kΩ
10 Ω
1.10 Binary Inputs
Binary Inputs
Nominal Voltage (

)
125 / 250 V
24 / 48 V
Level low
65 V
8 V
Level High
91 V
13 V
Impedance
120 kΩ
14 kΩ
Burden V
n
< 0.14W@125V
< 0.65W@250V
< 0.06W@24V
< 0.18W@48V
Continuous Overload
300 V
100 V
Maximum Overload (1 s)
460 V (4 x 

)
460 V (4 x 

)
Acquisition sampling rate
256 and 512 spc
256 and 512 spc
