GE DR60 - PMU Specification

DR60
76
DR60-TM-EN-2A
1.8 PMU Specification
PMU Specification
Number of simultaneous
PMU streams
4
Performance Class
P and M
Communication Protocol
C37.118.2
UDP or TCP
Communication mode
Commanded and
spontaneous
PMU data
Voltage and current
synchrophasors; frequency,
rate of
change of frequency and
sequence components
Ethernet interfaces
2 RJ45 or 2 LC connector
VT inputs
115 V nominal; up to 16
inputs
CT inputs
1 or 5 A nominal; up to 16
inputs
