GE DR60 - Type Tests DR60

DR60
DR60-TM-EN-2A
114
As tested per 60068-2-2
+55°C
Enclosure Protection IEC 60529
IP20
1.13 Type Tests DR60
EMC tests were performed according to IEC 60255-26 referring to the following
standards
Type Tests DR60
Test
Standard
Level
Electrostatic
discharge
IEC 61000-4-
2:2008
6kV contact / 8KV air (level 3)
RF immunity
IEC 61000-4-
3:2006
10 V/m (level 3)
Fast transient
disturbance
IEC 61000-4-
4:2012
Zone A
4kV / 5kHz
Surge immunity
IEC 61000-4-
5:2005
Zone A
Differential mode: 2 kV
Common mode: 4 kV
Conducted RF
immunity
IEC 61000-4-
6:2008
0.15MHz to 80MHz
10V/rms
Power magnetic
immunity
IEC 61000-4-
8:2009
30A/m continuous - 300A/m @ 1s (level 4)
Voltage dip,
short
interruptions and
voltage variation
immunity tests
IEC 61000-4-
11:2004
IEC 61000-4-
29:2000
▪ AC and DC voltage dips
Test level: 0% residual voltage
Duration time
a.c.: 1 cycle
d.c.: 16.6ms
▪ Test level: 40% residual voltage
Duration time
a.c.: 12 cycle
d.c.: 200ms
▪ Test level: 70% residual voltage
Duration time
a.c.: 30 cycle
d.c.: 500ms
