For information about the analog current inputs specifications, refer to Technical
Specifications Chapter.
Connections shall use screened/shielded cables with insulated flexible wires of 1.5 mm²
cross section and 5.08 mm pitch plug terminals voltage rating of 300Vrms.
5 Case Dimensions
5.1 DR60 Dimensions and Weight
Dimensions of the equipment
Height
222 mm / 8.7 in (5 U)
Width
222 mm / 8.7 in (½ 19'')
Depth
121 mm / 4.7 in
Weight
< 3.5 kg (< 7.72 lb)
DR60 dimensions are shown on the figure below.
DR60 Dimensions
