GOOSE
Subscriber
Configures the GOOSE subscriptions using
the SCL files from the IEDs publishing
GOOSE.
Reports
Associates the datasets to Report Control
Blocks to be published.
C37.118.2-2011
(PMU)
Configures the communication parameters
regarding the PMU streams according to
C37.118.2-2011
DNP3
Configures the communication parameters
of the DNP3 stream
Synchronization
Synchronization
Configure the synchronization
source/protocol, timezone and daylight
saving time parameters.
Recording
Recording
Configures the parameters of the DR60
recorders (Waveform, disturbance,
continuous disturbance and SOE), such as:
pre, post time, sampling rate and others.
Triggering
Thresholds
(RADR)
Contains the thresholds to trigger the
DR60 waveform and disturbance recorder
Equations
Allows the creation of logical equations
using the DR60 variables (inputs, logical
nodes parameters).
Matrix
Configures which thresholds,
binary/GOOSE inputs or equations will
trigger the DR60 recorders. Also,
configures the DR60 binary outputs.
1.3 Status Bar
Status bar presents the software name, the connection status (if it is connected, reading
or sending configurations), and the Ethernet IP address, as shown in the figure below.
DR60 Configurator Status Bar
2 Access Levels
