3.1.1 IP Address Scanning
The DR60 Configurator is able to scan the Ethernet network and recover the IP
Addresses of the connected DR60s. This tools is useful when the IP Address of the DR60
the user wants to communicate is not known.
The IP Address Scanning tool is located on the Communication setup screen.
3.2 Creating a New Configuration File
In order to create a new configuration, click on the <New> button on the initial screen
of the DR60 Configurator.
It opens a window to configure the order code of the equipment, according to hardware
configuration.
A Order Code: the order code must be created based on the equipment hardware
configuration. On each field insert the configuration of the respective slot. The order
code of the equipment is displayed on the label affixed on the equipment. For
additional information about the formation of the order code, refer to APPENDIX A.
B <Cancel>: this button cancels the order code edition and goes back to the initial
screen of the DR60 Configurator.
C <Ok>: this button confirms the order code edition and opens the main screen of the
DR60 Configurator.
It is also possible to create a new configuration file through the Main Screen of the
DR60 Configurator, by selecting the option New CID on the File menu.
3.3 Receiving an Equipment Configuration File
To receive an online equipment configuration, click on the <Receive> button on the
initial screen of the DR60 Configurator. The configurator will communicate with the IP
Address or serial configuration configured in the Communication Setup screen and
download the DR60 current configuration loading it on the main Screen of the DR60
Configurator.
It is also possible to receive an equipment configuration file from the Main Screen of
the DR60 Configurator, by selecting the option Receive Configuration on the Menu Bar.
After clicking the Receive button, an authentication window will pop up asking for a
user and a password to complete the operation.
The possible user names and passwords are:
