GE DR60 - Page 54

DR60
54
DR60-TM-EN-2A
V2
(PU)
Negative sequence voltage
and
V0
(PU)
Zero sequence voltage
and
I1
(kA)
Positive sequence current
and
I2
(kA)
Negative sequence current
and
I0
(kA)
Zero sequence current
and
THD
VP
(%)
Phase voltage total harmonic
distortion
and
THD
VN
(%)
Neutral voltage total harmonic
distortion
and
THD
IP
(%)
Phase current total harmonic
distortion
and
TDH
IN
(%)
Neutral current total harmonic
distortion
and
Derivative Measures
Description
Type
P
3θ
(MW/s)
Total active power
Q
3θ
(MVAr/s)
Total reactive power
S
3θ
(MVA/s)
Total apparent power
F
(Hz/s)
Frequency
V
P
(PU/s)
Phase voltages RMS
V
N
(PU/s)
Neutral voltages RMS
I
P
(kA/s)
Phase currents RMS
I
N
(kA/s)
Neutral currents RMS
Single-phase
Measures
Description
Type
F
(Hz)
Frequency
and
V
(PU)
Voltage
and
I
(kA)
Current
and
P
(MW)
Active Power
and
Q
(MVAr)
Reactive Power
and
S
(MVA)
Apparent Power
and
PF
Power Factor
and
THD
V
(%)
Voltage Total Harmonic
Distortion
and
THD
I
(%)
Current Total Harmonic
Distortion
and
Single-phase
Measures (Derivative)
Description
Type
F
(Hz/s)
Frequency
V
(PU/s)
Voltage
I
(kA/s)
Current
P
(MW)
Active Power
