GE Healthcare B30 - Extension Module N-FCREC; Extension Module N-FREC

System description
2-7
Extension Module N-FCREC
Figure 2-7 Module N-FCREC
(1) Recorder
(2) Paper compartment lever
(3) CO
2
measurement
(4) Water trap
(5) Tab for removing the module
(6) Sample gas inlet
(7) Gas outlet
Extension Module N-FREC
Figure 2-8 Module N-FREC
(1) Recorder
(2) Paper compartment lever
(3) Tab for removing the module
1
3
2
4
6
7
5
1
2
3
