General theory of operation
Invenia ABUS 2.0 – System Setup and Basic Service Manual 5-23
4700-0043-00 Rev. 4
Display arm assembly with Touchscreen Monitor
This assembly comprises the lower arm (also known as the
extension arm), the upper arm which is rotatable and which
swivels from side to side (called the Articulating Display Arm)
and the touchscreen monitor.
Figure 5-10. Display Arm and Monitor
The components of the arm are:
1.Shoulder joint
2.Extension arm
3.Elbow joint
4.Lift arm
5.Wrist joint
6.Display joint
