Figure 2: Back View of the iVent™201
Item Number
Description
1 Carrying handle
2 Keyboard connector
3 Remote alarm connector
4 External screen connector
5 LAN connector*
Do not remove connector cap. This connection
port is not in use
6 AC cable clip
7 RS 232 connectors (COM1 and COM2)
8 On/off switch (with cover)
9 High pressure oxygen inlet connector
