GE MEDICAL SYSTEMS
D
IRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
Chapter 4 Functional Checks 4-29
4-7-2 OP Panel Encoder Assy Validation
1.) Follow up the procedure 8-4-1 to run the scfpapitest program.
2.) Check the each Encoder in Table 4-8 on page 26.
4-7-3 OP Panel TGC Assay Validation
1.) Follow up the procedure section 4-7-1 on page 25 to run the scfpapitest program.
2.) Slide TGC pot and check up the value.
4-7-4 TGC Knob Set validation
1.) Follow up the procedure section 4-7-1 on page 25 to run the scfpapitest program.
2.) Slide TGC pot and check up the value.
4-7-5 A/N Key assy validation
1.) Boot up the system
2.) Press 'Comment' button
3.) Press A/N keyboard.
4-7-6 Trackball Assy validation
1.) Boot up the system
2.) Press the measurement button.
3.) Move the Trackball
4-7-7 OP Panel HUB Board Assy Validation
1.) Section 4-7-1 - Main Keyboard Assy validation on page 4-25 process.
2.) Section 4-7-5 - A/N Key assy validation on page 4-29 validation process.
3.) Section 4-7-6 - Trackball Assy validation on page 4-29 process.
NOTICE
While rotating or pressing encoders, Encoder message should be displayed in Log of Scfpapitest.exe
NOTICE
While sliding TGC pot, TGC message should be displayed.
NOTICE
While sliding TGC pot, TGC message should be displayed.
NOTICE
Each key should be displayed on the monitor display.
NOTICE
When you move the trackball in measurement mode, the cursor should be moved.
NOTICE
Main keyboard, A/N Keyboard and Trackball should be working.
