GE MEDICAL SYSTEMS
D
IRECTION 2300000, REVISION 2 LOGIQ™5 SERVICE MANUAL
Chapter 8 Replacement Procedures 8-173
8-10-5-5 Image Management Guide (cont’d)
5.) The SAVE AS menu appears.
6.) Specify Compression and Save As Type and press Save. The image is saved to the CD-ROM.
7.) When you have put all the images you want on the CD, press F3 to eject the CD-ROM. Select
CD Rewritable.
8.) Finalize the CD-ROM by selecting Yes. The CD-ROM is ejected from the system.
Figure 8-203 Save As Menu
Figure 8-204 Eject Media Menu
Figure 8-205 Finalize CD-ROM Menu
To Next Page
